MLOps Basics [Week 2]: Configurations – Hydra

hydra

MLOps Basics [Week 2]: Configurations – Hydra

βš™οΈ Configurations

Why do you need configurations? Configuration management is a necessary for managing complex software systems. Lack of configuration management can cause serious problems with reliability, uptime, and the ability to scale a system.

There are many ways to add configurations to the python code. The prominent ways are:

and many more…

I will be using Hydra.

In this post, I will be going through the following topics:

  • Basics of Hydra
  • Overridding configurations
  • Splitting configuration across multiple files
  • Variable Interpolation
  • How to run model with different parameter combinations?

πŸ‰ Basics ofΒ Hydra

First things first. Let’s install the library

πŸ— Installation

pip install hydra-core==1.1.0

Hydra operates on top of OmegaConf, which is a YAML based hierarchical configuration system, with support for merging configurations from multiple sources (files, CLI argument, environment variables) providing a consistent API regardless of how the configuration was created.

Let’s look at a basic yaml file and import it

preferences:
user: raviraja
trait: i_like_my_sleeping

Let’s load this file using OmegaConf

from omegaconf import OmegaConf
# loading
config = OmegaConf.load('config.yaml')
# accessing
print(config.preferences.user)
print(config["preferences"]["trait"])

Let’s load this file using Hydra

import hydra
from omegaconf import OmegaConf
@hydra.main(config_name="basic.yaml")
def main(cfg):
# Print the config file using `to_yaml` method which prints in a pretty manner
print(OmegaConf.to_yaml(cfg))
print(cfg.preferences.user)
if __name__ == "__main__":
main()
preferences:
user: raviraja
trait: i_like_my_bed
raviraja

Config can also be loaded without using hydra.main decorator in the following way:

from hydra import initialize, compose
initialize(".")  # Assume the configuration file is in the current folder
cfg = compose(config_name="basic.yaml")
print(OmegaConf.to_yaml(cfg))

πŸ“ Overriding configurations

By default the values which are allocated in the config file will be used. But we can also override the values of the variables during run time.

This can be done by πŸ‰ Override syntax

python main.py perferences.trait=i_like_stars
preferences:
user: raviraja
trait: i_like_stars

♻️ Converting the existing code intoΒ πŸ‰

Let’s convert all the parameters in the existing code into yaml format and load it using πŸ‰

Let’s create a folder called configs and a file inside it as config.yaml

The folder structure looks like

β”œβ”€β”€ configs
β”‚ └── config.yaml

The contents of the config.yaml is

model:
name: google/bert_uncased_L-2_H-128_A-2
tokenizer: google/bert_uncased_L-2_H-128_A-2
processing:
batch_size: 64
max_length: 128
training:
max_epochs: 1
log_every_n_steps: 10
deterministic: true
limit_train_batches: 0.25
limit_val_batches: 0.25

Now let’s load the file in the train.py code and use the values present in that file

# NOTE: Need to provide the path for configs folder and the config file name
@hydra.main(config_path="./configs", config_name="config")
def main(cfg):
# print(OmegaConf.to_yaml(cfg))
cola_data = DataModule(
cfg.model.tokenizer, cfg.processing.batch_size, cfg.processing.max_length
)
cola_model = ColaModel(cfg.model.name)
    checkpoint_callback = ModelCheckpoint(
dirpath="./models",
filename="best-checkpoint.ckpt",
monitor="valid/loss",
mode="min",
)
    wandb_logger = WandbLogger(project="MLOps Basics", entity="raviraja")
trainer = pl.Trainer(
max_epochs=cfg.training.max_epochs,
logger=wandb_logger,
callbacks=[checkpoint_callback, SamplesVisualisationLogger(cola_data)],
log_every_n_steps=cfg.training.log_every_n_steps,
deterministic=cfg.training.deterministic,
limit_train_batches=cfg.training.limit_train_batches,
limit_val_batches=cfg.training.limit_val_batches,
)
trainer.fit(cola_model, cola_data)

δ·– Splitting configuration across multipleΒ files

In the example we are exploring, the amount of variables are less only. But in real scenarios there could be lot of modules and each module may have many parameters. Having all those parameters in a single file can look messy. Fortunately πŸ‰ offers a way to have configurations in multiple files and can be tied together. This can be done via πŸ‰ configuration groups

Let’s create a separate folder model in the configs folder for containing the model specific configurations. Let’s create a file called default.yaml containing the default model configurations

The folder structure looks like:

β”œβ”€β”€ configs
β”‚ β”œβ”€β”€ config.yaml
β”‚ └── model
β”‚ └── default.yaml

The contents of the model/default.yaml looks like

name: google/bert_uncased_L-2_H-128_A-2 # model used for training the classifier
tokenizer: google/bert_uncased_L-2_H-128_A-2 # tokenizer used for processing the data

Now let’s modify the config.yaml

defaults:
- model: default

Let’s take a step to understand what’s going on.

What we have done here is:

  • Created a separate folder called model and then created a file called default.yaml
  • Β Shifted all the model specific parameters to that file
  • Β Created a new key called defaults(reserved keyword in πŸ‰) in the config.yaml file
  • Β defaults here is a list item
  • Β add a (key, value) to the defaults list -> model(this has to same as folder name): default (this has to same as file name)
  • Β Here we are saying to hydra that refer to model specific parameters in the model/default.yaml file.

The accessing stays the same.

model_name = cfg.model.name

For example, if have a database and want to configure different type of instances. Let’s say postgres, mongodb and want to keep postgres as the default. Then the config.yaml looks like:

defaults:
- database: postgres

The corresponding folder structure looks like:

β”œβ”€β”€ configs
β”‚ β”œβ”€β”€ config.yaml
β”‚ β”œβ”€β”€ database
β”‚ β”‚ └── postgres.yaml
β”‚ β”‚ └── mongodb.yaml

Now let’s create processing specific folder and training specific folder and shift the corresponding parameters to that files.

Final folder structure looks like:

β”œβ”€β”€ configs
β”‚ β”œβ”€β”€ config.yaml
β”‚ β”œβ”€β”€ model
β”‚ β”‚ └── default.yaml
β”‚ β”œβ”€β”€ processing
β”‚ β”‚ └── default.yaml
β”‚ └── training
β”‚ └── default.yaml

The contents of the config.yaml file looks like:

defaults:
- model: default
- processing: default
- training: default

πŸ•΅ Variable Interpolation

Some times variables can also depend on other variables. For example, which layer to use may depend on kind of dataset. As a simple example, let’s set the limit_val_batches variable values same as limit_training_batches.

This file training/default.yaml looks like:

max_epochs: 1
log_every_n_steps: 10
deterministic: true
limit_train_batches: 0.25
limit_val_batches: ${training.limit_train_batches}

When you load and print the complete config, the value will be printed as

print(OmegaConf.to_yaml(cfg))
${training.limit_train_batches}

In order to overcome this pass resolve=True to the OmegaConf.to_yaml call. i.e

print(OmegaConf.to_yaml(cfg, resolve=True))
0.25

πŸ’„ Color coding theΒ logs

Logging helps in understanding the status of the program. Having colorful logs will help in identifying the specific logs even faster (and also logs look prettier.)

This can be done easily in πŸ‰ without changing any logging code. (usually people define color syntax for each kind of log method / use different libraries which has color support). In πŸ‰ by chaning the default logging mode is sufficient.

In order to do this, we need to install a hydra extension:

pip install hydra_colorlog

Let’s override hydra/job_logging and hydra/hydra_logging in the config. The config.yaml looks like:

defaults:
- override hydra/job_logging: colorlog
- override hydra/hydra_logging: colorlog

Before color coding the logs look like:

After adding the colors:

By default, Hydra executes each script inside a different directory, to avoid overwriting results from different runs. The default name for the directory is outputs/<day>/<time>/

Each directory contains the output of your script, aΒ .hydra folder containing the configuration files used for the run, and a <name>.log file containing all the data that was sent to the logger.

πŸ‘Ÿ Running model with different parameter combinations

Sometimes you want to run the same application with multiple different configurations. This can be done in πŸ‰ via Multi-run

Use theβ€Šβ€”β€Šmultirun (-m) flag and pass a comma separated list specifying the values for each dimension you want to sweep.

For example, in order to run the application with epochs 1 and 2, the command looks like:

python train.py -m training.max_epochs=1,2

Then πŸ‰ launches 2 jobs:

If the parameters are spread over different folders means all the combinations will be taken. For example, by running the command

python train.py -m training.max_epochs=1,2 processing.batch_size=32,64,128

A total of 6 jobs will be launched

[2021-06-13 17:25:03,317][HYDRA] Launching 6 jobs locally
[2021-06-13 17:25:03,318][HYDRA] #0 : training.max_epochs=1 processing.batch_size=32
[2021-06-13 17:25:03,458][HYDRA] #1 : training.max_epochs=1 processing.batch_size=64
[2021-06-13 17:25:03,602][HYDRA] #2 : training.max_epochs=1 processing.batch_size=128
[2021-06-13 17:25:03,755][HYDRA] #3 : training.max_epochs=2 processing.batch_size=32
[2021-06-13 17:25:03,895][HYDRA] #4 : training.max_epochs=2 processing.batch_size=64
[2021-06-13 17:25:04,040][HYDRA] #5 : training.max_epochs=2 processing.batch_size=128

πŸ”š

This concludes the post. These are only a few capabilities of πŸ‰. There are many other functionalities like:

and much more… Refer to the original documentation for more information.

Complete code for this post can also be found here: Github
